Product Details
Tsurumi Pumps are world renown for dependability, performance and value. All Tsurumi water feature pumps are constructed of the highest quality materials and components for years of continuous use in ponds, waterfalls, fountains, and more.
The Tsurumi Low Level Manual Electric Submersible Pump are known as original residue dewatering pumps. They are able to pump down to the floor, even the smallest puddle can be pumped dry.
LSR drainage pump are the best for complete drainage of flat surfaces where a sump is not available. Ideal for decorative waterfalls and fountains, residential, commercial, industrial residual wastewater, construction site drainage, effluent transfer and Raw water supply from rivers or lakes.
Features:
Product Specifications
Liquid Type:
Details
Brand Name: Tsurumi
Model #: LSR2.4S
Pump Type: Submersible Residue Dewatering Pump
Max Pump Flow: 3744 GPH
Horse Power: 2/3 HP
Discharge Size: 2" NPT
Power: 115V / 60 Hz
Amperage: 5.9 A
Phase: Single
Power Cable Lenght: 32 ft
Max Head Height: 39.5 ft Aprox.
Min. Operating Water Level: 1/5" or 0.2"
Aprox. Dimensions: 8 1/4" Dia. x 11 3/8" H
Aprox. Pump Weight: 28 lbs
2 Years Limited Manufacturer Warranty
Reference Material
Products Specification (PDF)
Dimensional Drawing (PDF)
Operational Manual (PDF)
The Tsurumi Low Level Manual Electric Submersible Pump are known as original residue dewatering pumps. They are able to pump down to the floor, even the smallest puddle can be pumped dry.
LSR drainage pump are the best for complete drainage of flat surfaces where a sump is not available. Ideal for decorative waterfalls and fountains, residential, commercial, industrial residual wastewater, construction site drainage, effluent transfer and Raw water supply from rivers or lakes.
Features:
- Semi-vortex, urethane rubber impeller with ethylene propylene rubber casing increases wear resistance when pumpage contains abrasive particles
- Double inside mechanical seals with silicon carbide faces, (both top and bottom) running in an oil filled chamber and further protected by a lip seal running against a replaceable 430 stainless steel shaft sleeve provides for the most durable seal design available.
- Highly efficient, continuous duty, air filled, copper wound motor with class E insulation minimizes the cost of operation
- Built in thermal and amperage sensing protector prevents motor failure due to overloading or accidental run-dry conditions.
- Double shielded, permanently lubricated, high temperature C3 ball bearings rated for a B-10 life of 60,000 hours extend operational life.
- Top discharge, flow-thru design enables operation at low water levels (3/16“) for extended periods.
- 2 Year Manufacturer's Warranty.
Product Specifications
Liquid Type:
- Spring Water, Work drainage and muddy water
- Max. Water temperature: 140° F - 40°C
- Impeller: Semi-Vortex Type
- Double Mechanical Shaft Seal
- Shielded Ball Bearing
- Dry Submersible Induction Motor, 2 Pole
- Insulation class E
- Built-in Miniature Protector
- Lubricated with Turbine Oil VG32 (or SAE 10W-20)
Pump:
Motor:
Details
Brand Name: Tsurumi
Model #: LSR2.4S
Pump Type: Submersible Residue Dewatering Pump
Max Pump Flow: 3744 GPH
Horse Power: 2/3 HP
Discharge Size: 2" NPT
Power: 115V / 60 Hz
Amperage: 5.9 A
Phase: Single
Power Cable Lenght: 32 ft
Max Head Height: 39.5 ft Aprox.
Min. Operating Water Level: 1/5" or 0.2"
Aprox. Dimensions: 8 1/4" Dia. x 11 3/8" H
Aprox. Pump Weight: 28 lbs
2 Years Limited Manufacturer Warranty
